Luowave X410 PRO/PRO+ 1 MHz-7.2 GHz RF SDR 400MHz bandwidth/ch 4 Channel Xilinx RFSoC XCZU48DR FPGA Phase-Coherent < 1° RMS USRP Software Defined

The Luowave X410 PRO/PRO+ is a newly upgraded high-performance software-defined radio (SDR) platform developed by Wuhan Luoguang Electronics. As an advanced version of the X410, both the PRO and PRO+ models feature an upgraded core with the Xilinx XCZU48DR FPGA chip, significantly enhancing signal processing capabilities. The platform retains the cutting-edge architecture of the Xilinx Zynq UltraScale+ RFSoC, integrating a quad-core ARM processor and high-precision 14-bit ADC/14-bit DAC, with an ultra-wide frequency range coverage of 1MHz–7.2GHz (expandable to 8GHz).

Utilizing a two-stage superheterodyne architecture, it supports 4-channel independent transceiving, each with a 400MHz instantaneous bandwidth.

Moreover, the Luowave X410 PRO+ incorporates an innovative LO sharing design combined with the two-stage superheterodyne architecture, enabling 4-channel independent transceiving while maintaining a 400MHz instantaneous bandwidth per channel. It ensures exceptional phase coherence across multiple channels, with a phase consistency of better than 1°, making it an ideal hardware solution for phase-critical applications such as phased-array radar and MIMO communications.
